PERI UP Flex Facade Scaffolding in action
-
Extremely adaptable
Adjustments are carried out in a uniform grid arrangement of 25 cm which provides a high level of flexibility for complex facade scaffolding.
-
Gap-free decking levels
Each bay is covered completely with system decking and without any tripping hazards.
-
High load-bearing capacity
Up to Load Class 6 depending on the assembly.
גיליון נתוני מוצר
סוג פיגום
Facade
סוג השימוש
Working scaffold, protective scaffold
סוג בנייה
Steel
כיתת רוחב
SW 03, SW 06, SW 09, SW 12, SW 15
כיתת טעינה
LK 1, LK 2, LK 3, LK 4, LK 5, LK 6
גובה
Up to 24 meters
עקרון מבני
Advanced assembly system, according to TRBS 2121-1
תקן
EN 12810 and EN 12811
אורך שדה
50 cm, 75 cm, 100 cm, 125 cm, 150 cm, 200 cm, 250 cm, 300 cm
עומס מותר
Load class 1 to 4 (0.75 kN/m² - 3.00 kN/m²); Load class 1 to 6 (0.75 kN/m² - 6.00 kN/m²)
